Tuotteen nimi
Alfa 2.4/5GHz Omni Ulkoantenni 5/9dBi RP-SMA Male
Takuu
?
24 kuukautta
Valmistajan osanumero
AOA-2458-59-TSL
EAN
0708747432800
Alfa 2.4/5GHz 5/9dBi omni antenni – kaksitaajuus RP-SMA-liittimellä
- Kaksitaajuinen ulko-omniantenni 2,4 GHz ja 5 GHz Wi‑Fi-verkkoihin, 5 dBi vahvistus 2400–2483,5 MHz ja 8,4 dBi vahvistus 5150–5875 MHz parempaan kuuluvuuteen.
- SISO 1x1 -rakenne auttaa tarjoamaan vakaan yhteyden ulkokäytössä – sopii tukiasemiin ja pisteestä pisteeseen -Wi‑Fi-ratkaisuihin.
- Vedenpitävä RP-SMA Male -liitin luotettavaan ulkoasennukseen ja liitännän parempaan suojaan avoimissa olosuhteissa.
- Omnidirektionaalinen säteilykuvio jakaa signaalin laajalle alueelle ja auttaa parantamaan Wi‑Fi-peittoa ulkotiloissa.
- ALFA Network AOA-2458-59-TSL on ulkokäyttöön tarkoitettu kaksitaajuusantenni yhteensopiville Wi‑Fi-laitteille RP-SMA-liitännällä.
20.76 €
Varastossa
?
20.76 €
Varastossa
?
Yksityiskohtainen kuvaus
Tekniset tiedot
Langaton Verkko
Esiintymistiheys
2.4GHz, 5GHz
Antenni
Antennin Suunnittelu
Omni
Langattoman Antennin Taajuusalue Ja Vahvistus
2.400 - 2.483 (GHz) 5 (dBi), 5.150 - 5.875 (GHz) 8.4 (dBi)
Säteen leveys
360 ° Pystysuora
Polarisaatio
Lineaarinen
VSWR
< 2.0
Impedanssi
50 Ω
Liitin
RF-liittimet
(1) RP-SMA Male
Fysikaaliset Parametrit
Väri
Valkoinen
Mitat
Ø22 x 260 mm
Paino
0.07 kg
Käyttölämpötila
-40 °C - 85 °C
Ympäristö
Ulkotiloissa
